Specification: Thermal Conductivity: 1.9±10%W/mKThickness: 0.15 mm Dielectric Breakdown Voltage(Vac): 3.1 KV/mm Dielectric Breakdown Voltage(Vdc): 4.1 KV/mm Density: 1.8±5% g/cm³Operating Temperature: -30~120°C Reinforcement Carrier: Fiberglass mesh Holding Power 1000g@25°Cusing 1 in2: >10000 Holding Power 1000g@80°Cusing 1 in2: >10000 (T-Global guarantees a 6-month shelf life at maximum continuous storage temperature of 25°C for maintenance of controlled adhesion to the liner.) *Protective film may be different colors according to the model, it does not affect the function of the product. Application: Electronic components - 5G, Aerospace, AI, AIoT, AR/VR/MR/XR, Automotive, Consumer Devices, Datacom, Electric Vehicle, Electronic products, Energy Storage, Industrial, Lighting equipment, Medical, Military, Netcom, Panel, Power electronics, Robot, Servers, Smart Home, Telecom, etc. Operating Manual: 1.When using thermal conductive double-sided tape, keep the adhesive surface clean and dry. 2.After tearing off the protector of the thermal tape, pressed it evenly (just a little strength) with your fingers to make sure the tape has greater contact with the surface. 3.The viscosity of the thermal tape have initial viscosity (40% of its maximum viscosity) and persistent viscosity. At room temperature, it takes 72 hours to achieve the maximum adhesive strength. 4.In the application process, appropriate heating (60 ~ 70°C) will greatly contribute to the effective of adhesive, and as soon as possible to achieve maximum adhesion. In the lower temperature of the winter, appropriate heating is a tip to increase the viscosity of the thermal tape. Storage: Store in a cool, dry place away from direct sunlight.
